AMBU® AURAGAIN™ DISPOSABLE LARYNGEAL MASKS
• Laryngeal Mask N 3
• Patient weight: 30-50 kg
• Max mask ET-Tubes Max (Ø of endotracheal tube): 6.5 mm
• Gastric-Tube max (FR): 16 FR
• Maximum cuff inflation volume: 20 ml
The AuraGain satisfies 3 fundamental airway management needs by integrating gastric access and intubation capability in an anatomically curved single-use device that facilitates rapid establishment of a safe airway.
• Rapid placement
The soft rounded curve of the AuraGain, pre-formed to follow the anatomy of the human airway, ensures rapid placement and guarantees long-term performance. The thin and soft cuff of the AuraGain is designed to deliver high seal pressures.
• Gastric control
The integrated gastric access channel is designed with a low friction inner surface to facilitate easy placement of a gastric tube, to enable active and passive management of gastric content and prevent gastric insufflation.
• Integrated intubation capability
It provides the added safety feature of intubation capability. This means that in case of an unexpected difficult airway, or a "Cannot Intubate - Cannot mask Ventilate" (CI-CV) situation, where the endgame is to intubate the patient, AuraGain can be used as conduit for direct endotracheal intubation assisted by a flexible scope.
• All-round versatility
Rapid placement, high seal pressure, gastric access and intubation capability make the AuraGain the obvious and safe choice for every procedure where a laryngeal mask is indicated.
Ambu® AURAGAIN™ VENTILATION, INTUBATION, GASTRIC ACCESS
Soft bite absorption area with helpful markings and accessory size information.
Navigation marks for guiding flexible endoscopes.
Direct endotracheal intubation using a flexible scope and standard ET-tubes.
Technical Specifications
Maximum intra-cuff pressure: 60 cm H2O
Airway connector: 15 mm ISO 5356-1
Tube/cuff material: PVC (latex and phthalates free)
Complete range for neonatal (AuraGain only), pediatric and adult patients
Packaged sterile and ready for use
Colour coded pouch with directions for use
