OTOPLUS DC - ENT UNIT, 1 pc.

Description

OTOPLUS DC ENT UNIT

Otoplus unit with additional column, to be used for diagnostic equipment (light source, camera or printer) and a support pole for monitor.

The E.N.T. unit has rubber pivoting castors, a working surface made of scratch-proof rolled sections, 2 small and one large drawers provided of removable internal partitions, one drawer with inside germicidal lamps to keep instrument sterilization.
Otoplus is provided with a silent suction pump of 34 l/min, with power supply complete with dim adjustment device for Clar/Storz lamp, larynx-mirror warmer, twin-cylinder dry compressor for tubal insufflation, 2-litres distilled water tank with acoustic signal for reserve level.

The articulated arm with instrument holding tray is complete with terminal suction cannula and terminal insufflation cannula, ear rinsing syringe with automatic water temperature control, (a microprocessor keeps temperature at a constant level of 37 °C).

Size: 1250 x 540 x h 850 mm.

Power 230 V - 50 Hz (Available 110 V - 60 Hz).
Made in Italy.

Technical Specifications

• Additional column
• Support pole for monitor
• Water temperature control
• Dimmer for Clar/Storz lamp
• Suction pump of 34 l/ min with safety control valve to prevent overflow
• Insufflator
• Space for optional medication kit (27542)
• Ear rinsing medication syringe
• Compartment for water tank
• Pivoting castors
• Space for optional hopper frame drawers (same as 27555)
• Drawer with germicidal lamp
• Larinx-mirror warmer
